| Specification |
Description |
| Part Number |
ISD400-1111 |
| Manufacturer |
Sick |
| Part Category |
Data Transmission Unit |
| Power Supply |
DC 18 V ... 30 V |
| Power Consumption |
≤ 4.8 W (unloaded) |
| Connection Type |
Plug, M12, 4-pin |
| Protection Class |
IP65 |
| Insulation Class |
III |
| Transmission Range |
0.2 m ... 180 m |
| Light Source |
LED, infrared (880 nm) |
| Typical Light Spot Size (Distance) |
1.75 m (at 100 m) |
| Opening Angle |
Approximately ± 0.5° |
| Interface |
PROFIBUS DP |
| Data Transmission Rate |
3 Mbit/s |
| Digital Input |
Uv: transmitter deactivated |
| Digital Output |
Type: PNP, Signal delay: ≤ 1 µs, + 2 Tbit (only with PROFIBUS) |
| Electromagnetic Compatibility (EMC) |
EN 61000-6-2, EN 61000-6-4 |
| Operating Temperature |
–25 °C ... +55 °C |
| Storage Temperature |
–40 °C ... +75 °C |
| Dimensions |
105 mm x 83 mm x 98 mm |
| Weight |
Not specified |
| Additional Features |
LC display with function keys, optical alignment aid, multifunctional input |
The ISD400-1111 from Sick is a robust data transmission unit designed for reliable optical data transfer. It operates within a wide voltage range of 18 to 30 V DC and consumes minimal power. The unit features a durable M12, 4-pin connection and is rated IP65 for protection against dust and water ingress. With a transmission range of up to 180 meters and an infrared LED light source, it ensures efficient data communication. The device supports PROFIBUS DP interface with a data transmission rate of 3 Mbit/s. It is equipped with an LC display for easy operation and an optical alignment aid for precise setup. The ISD400-1111 is suitable for various industrial applications, offering high performance and reliability in challenging environments.
The Sick ISD400-1111 is a high-performance optical data transmission unit designed to facilitate reliable and efficient data communication in industrial environments. This unit operates within a transmission range of 0.2 meters to 180 meters, utilizing an infrared LED light source with a wavelength of 880 nm. The ISD400-1111 is equipped with a PROFIBUS DP interface, supporting data transmission speeds up to 3 Mbit/s, ensuring seamless integration with existing industrial networks.
Engineered for durability, the ISD400-1111 features an IP65-rated enclosure, providing robust protection against dust and water ingress. The unit operates within a wide temperature range of -25°C to +55°C, making it suitable for various industrial applications. The device is powered by a DC voltage range of 18 V to 30 V and consumes a maximum power of 4.8 W.
The ISD400-1111 includes a 4-pin M12 connector for easy installation and connectivity. It also features a digital input for deactivating the transmitter and a PNP digital output with a signal delay of less than 1 µs, plus 2 Tbit for PROFIBUS applications. The typical light spot size at a distance of 100 meters is 1.75 meters, with an opening angle of approximately ±0.5°.
This optical data transmission unit is ideal for applications requiring precise and reliable data transfer over long distances, such as automated material handling systems, conveyor systems, and other industrial automation processes. The ISD400-1111's advanced features and robust design make it a dependable choice for enhancing communication efficiency in demanding industrial settings.
