Specification & Description
| Specification | Description |
|---|---|
| Part Number | C40E-0703AN310 |
| Alternative Part Number | C40E0703AN310 |
| Manufacturer | Sick |
| Product Type | Safety Light Curtain |
| Resolution | 30 mm |
| Protective Field Height | 750 mm |
| System Component | Receiver |
| Range | 6 m |
| Synchronization | Optical synchronization |
| Safety Type | Type 4 (IEC 61496-1) |
| Safety Integrity Level | SIL3 (IEC 61508) |
| Performance Level | PL e (EN ISO 13849) |
| Probability of Dangerous Failure per Hour | 15 * 10^-9 (EN ISO 13849) |
| Service Life | 20 years (EN ISO 13849) |
| Minimum Output Switching State | At least one output switching element (OSSD) is in the OFF state. |
| Safety Operation | Yes |
| Interface | System connector M12, 5-pin |
| Cable Connection Direction | Straight |
| Wire Cross-Section | 0.25 mm² |
| Permissible Cable Length | ≤ 15 m |
| Display Elements | 7-segment display |
| Protection Class | III (IEC 61140) |
| Housing Material | Aluminum extruded profile |
| Dimensions | 48 mm x 40 mm (cross-section) |
| Weight | 1.700 g |
| Environmental Protection | IP65 (IEC 60529) |
| Operating Ambient Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Humidity | 15% to 95%, non-condensing |
| Vibration Resistance | 5 g, 10 Hz to 55 Hz (EN 60068-2-6) |
| Shock Resistance | 10 g, 16 ms (EN 60068-2-27) |
The Sick C40E-0703AN310 is a high-performance safety light curtain from the C4000 Eco series, designed to provide reliable and efficient protection for various industrial applications. This part features a resolution of 30 mm and a protective field height of 750 mm, making it suitable for safeguarding larger areas. With a range of up to 6 meters, it ensures broad coverage and is equipped with optical synchronization to enhance its operational reliability.
Constructed with a robust aluminum extruded profile, the C40E-0703AN310 is built to withstand challenging industrial environments. It operates within a temperature range of 0 °C to +55 °C and is rated IP65, ensuring protection against dust ingress and water jets. This model also supports a direct cable connection with a system connector of M12, 5-pin, and accommodates a conductor cross-section of 0.25 mm².
The safety outputs of this device include two PNP semiconductor outputs, which are short-circuit proof and monitored for cross faults, providing a high level of operational security. The C40E-0703AN310 is classified as a Type 4 safety device according to IEC 61496-1, with a safety integrity level of SIL3 (IEC 61508) and a performance level of PL e (EN ISO 13849), indicating its capability to handle high-risk applications.
This safety light curtain is an ideal solution for manufacturers seeking to enhance workplace safety without compromising on system efficiency or operational space. Its straightforward design and reliable performance make it a valuable addition to any safety system requiring high levels of protection and minimal maintenance.
