Specification & Description
| Specification | Description |
|---|---|
| Part Number | 6SL3120-1TE21-0AD0 |
| Alternative Part Number | 6SL31201TE210AD0 |
| Manufacturer | Siemens |
| Product Type | Single Motor Module |
| Input Voltage | DC 510 ... 720 V |
| Output Voltage | 3-phase 400 V |
| Output Current | 9 A |
| Base Load Current IH | 7.7 A |
| Rated Value IN | 11.0 A |
| Maximum Current Demand | 27.0 A |
| Electronics Power Supply | 4.1 kW |
| Rated Pulse Frequency | 4.00 kHz |
| Type Power | 4.8 kW (Based on IN) |
| Current Carrying Capacity | 650 Hz |
| DC Link Capacitance | 110 µF |
| Output Frequency for Servo Control | 300 Hz |
| Output Frequency for Vector Control | 600 Hz |
| Output Frequency for V/f Control | 600 Hz |
| Installation Altitude | Up to 1000 m (3281 ft) without derating |
| Cooling Requirement | Internal air cooling |
| Ambient Operating Temperature | 0 ... 40 °C (32 ... 104 °F) |
| Maximum Motor Cable Length | 50 m (164 ft) shielded, 75 m (246 ft) unshielded |
| Conductor Cross-Section | 2 ... 6 mm² (16 ... 10 AWG) |
| Compliance with Standards | SIL 2 acc. to IEC 61508, PL d acc. to EN ISO 13849-1, Category 3 acc. to EN ISO 13849-1, CE, cULus |
| Degree of Protection | IP20 / UL open type |
The Siemens 6SL3120-1TE21-0AD0 is a high-performance Single Motor Module designed to seamlessly integrate with a variety of industrial automation systems. This module is part of the SINAMICS S120 series and is engineered to provide precise and efficient control for single motors. With an input voltage range of 480V AC and a DC link voltage of up to 720V, it is well-suited for demanding applications.
The module boasts a compact booksize format, making it an ideal choice for space-constrained environments. It features a robust design with a degree of protection of IP20, ensuring durability and reliability in industrial settings. The unit is capable of delivering an output current of 9A, which allows it to handle a wide range of motor-driven applications.
Equipped with advanced technology, the Siemens 6SL3120-1TE21-0AD0 ensures smooth and energy-efficient operation. Its integration capabilities with various communication networks enhance its versatility, making it a smart choice for modern automation tasks. The module's technical specifications include a power loss of typically 0.06 kW to a maximum of 0.10 kW, and a sound pressure level of 60 dB, which contributes to a quieter and more comfortable working environment.
This motor module is designed for easy installation and maintenance, with a clear focus on high usability and minimal downtime. It is suitable for a variety of industrial applications, including but not limited to, conveyor systems, pumps, fans, and processing machinery. The Siemens 6SL3120-1TE21-0AD0 is a testament to Siemens' commitment to quality, innovation, and efficiency in the field of industrial automation.
Commonly Asked Questions
Is my order covered by a warranty?
Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.
Read more...What payment methods do you accept?
We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.
Read more...Is Marvo a credible parts supplier?
Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.
Read more...Have steps been taken to ensure quality control?
Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.
Read more...How do I create an account?
Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.
Read more...Peace of mind with every purchase
Thomas Roland Geaughan
‘Prompt and expert service. Ease of access to find the parts I needed.’
Martin Ruml
‘Rapid delivery.’
Martin Juřica
‘Fast offer, short delivery time.’
Irene
‘Fast delivery and prompt action.’
Nathalie Jolicoeur
‘Great service. Thank you.’
Advance Lifts
‘Great customer service , we needed some assistance quickly and received it.’
Martin Ruml
‘Rapid delivery.’
Andreas Boehm
‘Excellent service. The right gear and the right price,well packed and delivered on time.’
Muswalin
‘Good packing, quickly delivery and responsible.’
Similar Products
Our service to you
Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.
No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.
Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.
Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.
Frequently Asked Questions
What type of cooling does the Siemens Single Motor Module use?
The Siemens Single Motor Module utilises internal air cooling to maintain optimal operating temperatures during use.
Can the Siemens Single Motor Module be used for servo control?
Yes, the module is capable of output frequencies suitable for servo control applications, with specific parameters detailed in the technical specifications.
What is the typical power loss for this motor module?
The typical power loss for the motor module includes the losses of the 24 V DC electronics power supply, and it is specified in the general technical specifications of the product.
What are the ambient operating conditions for the Siemens Single Motor Module?
The module can operate within an ambient temperature range of 0 to 40 degrees Celsius and at an installation altitude of up to 1000 meters without derating.
What is the degree of protection for the Siemens Single Motor Module?
The module has a degree of protection rated at IP20, indicating that it is protected against solid objects larger than 12.5 mm but not against water ingress.
What are the compliance standards for the Siemens Single Motor Module?
The module complies with standards such as SIL 2 according to IEC 61508, PL d according to EN ISO 13849-1, and Category 3 according to EN ISO 13849-1, and it also carries CE and cULus certifications.
What is the sound pressure level of the Siemens Single Motor Module?
The sound pressure level of the module is specified at 60.0 dB, measured at a distance of 1 meter.
What type of construction does the Siemens Single Motor Module have?
The module features a booksize construction, which is a compact and space-saving design suitable for integration into various industrial applications.
Is the Siemens Single Motor Module suitable for vector control?
Yes, the module is designed to handle output frequencies that are appropriate for vector control applications.
What is the rated output current of the Siemens Single Motor Module?
The rated output current of the module is 9.0 A, with additional details available in the rated data section of the technical specifications.
