Specification & Description
| Specification | Description |
|---|---|
| Part Number | 6SL3055-0AA00-5KA3 |
| Alternative Part Number | 6SL30550AA005KA3 |
| Manufacturer | Siemens |
| Category | General Automation |
| Description | Sensor Module for SINAMICS Drives |
| Current | ≤0.30 A |
| Voltage | 24 V dc |
| Compatible Encoders | Encoders with a maximum frequency of 500 kHz and SSI transfer rate of 100 kBaud |
| Signal Division | Maximum interpolation of 16384 times 14 bit |
| Connectors | M23 round connector for measuring systems, M17 round connector for temperature sensors |
| Output | Connector with IP67 protection |
| Mechanical Data | IP67 protection grade, weight 0.70 kg |
| Dimensions | Width: 117.6 mm, Height: 43.1 mm, Depth: 127.0 mm |
| Consumption | 0.16 A at 24 V DC from DRIVE-CLiQ power supply |
| Encoder Power Supply | 0.35 A for integrated measuring encoder interface at 5 V DC |
| General Technical Data | Maximum losses of 4.5 W, cable length up to 3 m for measuring systems |
| Compliance | cULus compliant |
| Commodity Code | 85049099 |
The Siemens 6SL3055-0AA00-5KA3 is a high-precision sensor module designed to enhance the performance and accuracy of SINAMICS drive systems. This sensor module is part of the SME125 series and is engineered to work seamlessly with absolute encoders, including those utilising EnDat 2.1 interfaces. It is also compatible with PTC and KTY temperature sensors, ensuring comprehensive monitoring and feedback for drive systems.
Crafted with a focus on durability, the module boasts an IP67 rating for protection against dust and water ingress, making it suitable for challenging industrial environments. The module's secure electrical isolation safeguards against potential electrical interference, thus maintaining the integrity of the sensor signals.
With a compact design, the Siemens 6SL3055-0AA00-5KA3 sensor module is easy to integrate into existing setups, providing a straightforward solution for system upgrades or new installations. Its technical capabilities include a maximum encoder frequency of 500 kHz and an SSI baud rate of 100 kBaud, which allows for high-speed data transmission and ensures real-time control and monitoring of the drive system.
This sensor module is an essential component for those seeking to optimise their drive solutions, offering reliability and precision in a wide range of industrial applications. Whether it's for manufacturing automation, CNC machinery, or other sophisticated motion control systems, the Siemens 6SL3055-0AA00-5KA3 is a trusted choice for professionals looking to enhance their operational efficiency and machine performance.
Commonly Asked Questions
Is my order covered by a warranty?
Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.
Read more...What payment methods do you accept?
We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.
Read more...Is Marvo a credible parts supplier?
Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.
Read more...Have steps been taken to ensure quality control?
Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.
Read more...How do I create an account?
Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.
Read more...Peace of mind with every purchase
Blažej Knežo
‘Quick response and fast delivery of the product.’
Andreas Boehm
‘Excellent service. The right gear and the right price,well packed and delivered on time.’
Milan Kosík
‘Large selection of spare parts, fast delivery.’
Kayden
‘Services is great.’
Advance Lifts
‘Great customer service , we needed some assistance quickly and received it.’
Ms. Mia
‘Quick response, good item, delivery on schedule.’
Martin Ruml
‘Rapid delivery.’
Blažej Knežo
‘Quick response and fast delivery of the product.’
Andreas Boehm
‘Excellent service. The right gear and the right price,well packed and delivered on time.’
Our service to you
Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.
No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.
Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.
Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.
Frequently Asked Questions
What is the purpose of the Siemens Sensor Module?
The Siemens Sensor Module is designed for use with SINAMICS drives, providing precise sensor data for monitoring and controlling motion in industrial automation systems.
Can this sensor module be used with any encoder type?
The sensor module is compatible with various encoders, including absolute encoders EnDat 2.1, SSI with incremental signals, and others that comply with the module's specifications.
What are the electrical requirements for this sensor module?
The sensor module operates at a supply voltage of 24 V dc and has a typical current consumption of 0.16 A, making it suitable for integration into various industrial control systems.
What type of connectors does this sensor module support?
The module features several connectors, including an M23 round connector for the measuring system and an M17 round connector for the temperature sensor, ensuring versatile connectivity options.
Is the sensor module protected against environmental factors?
Yes, the sensor module is designed with an IP67 protection rating, making it dust-tight and capable of withstanding temporary immersion in water, suitable for harsh industrial environments.
What is the maximum encoder frequency the sensor module can handle?
The sensor module can handle a maximum encoder frequency of up to 500 kHz, allowing it to work with high-speed applications.
How does the sensor module connect to a SINAMICS drive system?
The sensor module connects to a SINAMICS drive system via the DRIVE-CLiQ interface, providing seamless communication and integration.
What is the weight and size of the sensor module?
The sensor module weighs approximately 0.74 kg and has dimensions of 117.6 mm in width, 43.1 mm in height, and 127.0 mm in depth, making it compact for industrial applications.
Can the sensor module be used for temperature monitoring?
Yes, the sensor module includes a dedicated connector for a temperature sensor, allowing it to monitor temperature as part of its functionality.
What is the maximum cable length supported by the sensor module for the measuring system?
For the measuring system, the sensor module supports a maximum cable length of 3 meters, ensuring reliable data transmission over a reasonable distance.
