Specification & Description
| Specification | Description |
|---|---|
| Part Number | 6EP1336-3BA00 |
| Manufacturer | Siemens |
| Category | General Automation |
| Input | 1-phase AC |
| Supply Voltage (AC) | 120 V / 230 V |
| Input Voltage Range (AC) | 85 - 132 V / 176 - 264 V |
| Rated Line Frequency | 50 / 60 Hz |
| Input Current | 7.7 A (120 V) / 3.5 A (230 V) |
| Output | Controlled, isolated DC voltage |
| Rated Output Voltage | 24 V DC |
| Adjustment Range | 24 - 28.8 V |
| Rated Output Current | 20 A |
| Overvoltage Resistance | 2.3 × Vin rated, 1.3 ms |
| Mains Buffering | 20 ms (at Vin = 230 V) |
| Operating Temperature | 0 - 70 °C |
| Storage Temperature | -40 - +85 °C |
| Connection Technology | Screw-type terminals |
| Protection Class | Class I |
| Degree of Protection (EN 60529) | IP20 |
| EMC | EN 55022 Class B, EN 61000-3-2, EN 61000-6-2 |
| Approvals | CE, UL/cUL (CSA), GL, ABS |
| Dimensions (W x H x D) | 160 mm x 125 mm x 125 mm |
| Weight | Approx. 2.2 kg |
| Installation | Snaps onto DIN rail EN 60715 35x7.5/15 |
Introducing the Siemens 6EP1336-3BA00: A Reliable and Efficient Power Supply Solution
The Siemens 6EP1336-3BA00 is a high-performance, modular power supply designed to provide a stable and reliable source of 24V DC output at 20A. This versatile power supply is perfect for a wide range of industrial automation applications, ensuring smooth and efficient operation of your equipment.
Key Features:
- Input voltage range: 85-132V AC (single-phase) or 176-264V AC (dual-phase)
- Output voltage: 24V DC, adjustable from 24 to 28.8V
- Rated output current: 20A
- High efficiency: Approximately 89% at rated output voltage and current
- Robust design: Built to withstand overvoltage resistance of 2.3 times the rated input voltage for 1.3ms
- Mains buffering: 20ms at rated output current and 230V AC input voltage
- Short-circuit protection: Features a constant current characteristic of approximately 23A or latching shutdown
- Parallel switching capability: Allows for enhanced performance by connecting up to two units in parallel
- Compliance with safety standards: CE mark, UL/cUL (CSA) approval, ATEX (EX) II 3G Ex nA nC IIC T3 Gc, and marine approval from GL and ABS
- Ambient operating temperature range: 0 to 70°C
The Siemens 6EP1336-3BA00 power supply is designed with user convenience in mind, featuring screw-type terminals for easy installation and a compact form factor that can be easily mounted on a DIN rail. The green LED indicator provides a visual confirmation of the 24V output status, while the optional signalling module (6EP1961-3BA10) offers additional monitoring capabilities.
Whether you're looking to power industrial control systems, automation equipment, or other critical applications, the Siemens 6EP1336-3BA00 power supply is a reliable and efficient choice that delivers consistent performance and peace of mind. Discover the benefits of this exceptional power supply solution at Marvo today.
Commonly Asked Questions
Is my order covered by a warranty?
Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.
Read more...What payment methods do you accept?
We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.
Read more...Is Marvo a credible parts supplier?
Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.
Read more...Have steps been taken to ensure quality control?
Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.
Read more...How do I create an account?
Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.
Read more...Peace of mind with every purchase
Dan
‘The ordering was fast and efficient, and everything arrived just as they said it would.’
Julien
‘Perfect quick delivery, good service.’
Blažej Knežo
‘Quick response and fast delivery of the product.’
Milan Kosík
‘Large selection of spare parts, fast delivery.’
Muswalin
‘Good packing, quickly delivery and responsible.’
Ms. Mia
‘Quick response, good item, delivery on schedule.’
Anna
‘I can recommend quick, efficient, and professional.’
Andreas Boehm
‘Excellent service. The right gear and the right price,well packed and delivered on time.’
Irene
‘Fast delivery and prompt action.’
Similar Products
Our service to you
Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.
No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.
Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.
Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.
Frequently Asked Questions
What is the input voltage range for this Siemens power supply?
The 6EP1336-3BA00 power supply has two input voltage ranges: 85-132 V AC for the 120 V nominal value and 176-264 V AC for the 230 V nominal value.
Is this power supply suitable for single-phase or three-phase input?
The Siemens 6EP1336-3BA00 power supply is designed for single-phase AC input.
What is the output voltage and current rating of this power supply?
The 6EP1336-3BA00 power supply provides a stabilized output voltage of 24 V DC and a rated current of 20 A.
Is the output voltage adjustable?
Yes, the output voltage of the 6EP1336-3BA00 power supply can be adjusted within a range of 24 to 28.8 V DC using a potentiometer.
Can this power supply be used in parallel for enhanced performance?
Yes, the Siemens 6EP1336-3BA00 power supply can be used in parallel with up to 2 units for enhanced performance.
What is the efficiency of this power supply?
The 6EP1336-3BA00 power supply has an approximate efficiency of 89% at rated output voltage and current.
What is the operating temperature range for this power supply?
The Siemens 6EP1336-3BA00 power supply can operate within an ambient temperature range of 0 to 70°C.
What type of connection technology does this power supply use?
The 6EP1336-3BA00 power supply uses screw-type terminals for its connections.
Does this power supply have short-circuit protection?
Yes, the Siemens 6EP1336-3BA00 power supply features short-circuit protection with a constant current characteristic of approximately 23 A or latching shutdown.
What is the degree of protection for this power supply?
The 6EP1336-3BA00 power supply has a degree of protection of IP20 according to EN 60529.
