Sick YG8U14-020VA3XLEAX

Name: YG8U14-020VA3XLEAX
Brand: Sick
SKU: YG8U14-020VA3XLEAX
Price: 22.98 GBP
Availability: InStock

Wrong part? Click here

£22.98 (ex. VAT)

1 ready to ship

Learn more about our conditions.

Image shown may not reflect the final product

Marvo Stock ID MV-15LMP

HS Code 85365080

SKU YG8U14-020VA3XLEAX

Condition New unsealed

Warranty 12 months

Weight (kg) 0.05

Length (mm) 25.00

Width (mm) 4.80

Height (mm) 20.00

Express delivery

Lightning fast delivery if ordered within 00:00:00

Need it urgently?

Call: +44 20 4570 3439

Quoting Marvo Stock ID: MV-15LMP

Select condition

We're working hard to deliver your orders on time over the holiday period, but please be aware that some lead times may be extended.

Learn more about our conditions.

Returns Hassle-free returns

Thumbs up No hidden fees or duties

Shipping Swift dispatch and delivery

Similar Products

MSLE03-14011

£306.18 (ex. VAT)

RTP2427S11

£56.78 (ex. VAT)

HLGS2050F811HLGE2050F811

£185.88 (ex. VAT)

C4MT-04214ABB03DB0

£433.80 (ex. VAT)

IME08-02BPSVT0SS12

£42.19 (ex. VAT)

C40S-1603AA310

£551.60 (ex. VAT)

More about this product

Specification & Description

View now

Commonly Asked Questions

View now

Customer Reviews

View now

Specification & Description

Specification	Description
Part Number	YG8U14-020VA3XLEAX
Manufacturer	Sick
Accessory Group	Plug connectors and cables
Accessory Family	Connecting cables
Connection Type Head A	Female connector, M8, 4-pin, angled, A-coded
Connection Type Head B	Flying leads
Locking Plug Connector	Screw connection
Connector Material	TPU
Connector Colour	Black
Locking Nut Material	Zinc die-cast, nickel-plated
Seal Material	FKM
Tightening Torque	0.4 Nm
Width Across Flats	9 mm
Cable Length	2 m
Cable Type	4-wire, PVC
Jacket Material	PVC
Jacket Colour	Grey
Cable Diameter	4.8 mm
Conductor Cross-Section	0.25 mm²
Shielding	Unshielded
Bending Radius (Flexible Use)	> 10 x cable diameter
Bending Radius (Stationary)	> 5 x cable diameter
Reference Voltage	≤ 60 V DC
Rated Impulse Voltage	1.5 kV
Current Loading	4A
Signal Type	Sensor/actuator cable
Application	Zones with chemicals
Authorisations	UL
UL File Number	E335179
Enclosure Rating	IP65 / IP66K / IP67
Operating Temperature	-5 °C to +80 °C (flexible use), -30 °C to +80 °C (stationary), -25 °C to +85 °C (head)
Pollution Degree	3
Insulation Resistance	100 MΩ
Overvoltage Category	III
Contact Resistance	30 mΩ
Thermal Resistance	Flame-resistant according to UL 1581 VW1 / CSA FT1
ECLASS Classification	5.0: 19030312, 5.1.4: 19030312, 6.0: 27060304, 6.2: 27060304, 7.0: 27060304, 8.0: 27060304, 8.1: 27060304, 9.0: 27060304, 10.0: 27060304, 11.0: 27060304, 12.0: 27060304
ETIM Classification	5.0: EC000830, 6.0: EC000830, 7.0: EC003249, 8.0: EC003249
UNSPSC Classification	16.0901: 26121604

The Sick YG8U14-020VA3XLEAX is a high-quality sensor/actuator cable designed to meet the demanding requirements of industrial applications. This robust cable features a female M8 connector with 4 pins, angled for ease of installation in tight spaces. The connector is A-coded and secured with a screw connection, ensuring a reliable and stable connection.

The cable itself is 2 metres long and consists of 4 unshielded wires encased in a durable PVC jacket, which is grey in colour. The cable has a diameter of 4.8 mm and a conductor cross-section of 0.25 mm², making it suitable for a variety of sensor and actuator applications. It is designed to operate in a wide temperature range, from -30°C to +80°C when stationary, and from -5°C to +80°C in flexible use, making it versatile for different environmental conditions.

The YG8U14-020VA3XLEAX is rated for a nominal voltage of 50 V AC and 60 V DC, with a current loading capacity of 4A. It also boasts an impressive insulation resistance of 100 MΩ and a rated impulse voltage of 1.5 kV. The connector material is made from TPU, with a zinc die-cast, nickel-plated locking nut, and an FKM seal, ensuring durability and longevity.

This cable is UL certified and has an enclosure rating of IP65, IP66K, and IP67, providing excellent protection against dust and water ingress. It is particularly suited for use in environments with chemicals, making it a reliable choice for various industrial applications.

Commonly Asked Questions

Is my order covered by a warranty?

Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.

What payment methods do you accept?

We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.

Is Marvo a credible parts supplier?

Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.

Have steps been taken to ensure quality control?

Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.

How do I create an account?

Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.

Peace of mind with every purchase

Dan

‘The ordering was fast and efficient, and everything arrived just as they said it would.’

Julien

‘Perfect quick delivery, good service.’

Thomas Roland Geaughan

‘Prompt and expert service. Ease of access to find the parts I needed.’

Martin Ruml

‘Rapid delivery.’

Milan Kosík

‘Large selection of spare parts, fast delivery.’

Kayden

‘Services is great.’

Anna

‘I can recommend quick, efficient, and professional.’

Martin Juřica

‘Fast offer, short delivery time.’

Andreas Boehm

‘Excellent service. The right gear and the right price,well packed and delivered on time.’

Muswalin

‘Good packing, quickly delivery and responsible.’

Julien

‘Perfect quick delivery, good service.’

Blažej Knežo

‘Quick response and fast delivery of the product.’

Milan Kosík

‘Large selection of spare parts, fast delivery.’

Learn more about Marvo

Our service to you

Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.

No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.

Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.

Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.

Frequently Asked Questions

What type of cable is this?

This is a sensor/actuator cable designed for industrial applications.

What are the connection types for this cable?

The cable has a female connector, M8, 4-pin, angled, A-coded on one end and flying leads on the other end.

What is the length of the cable?

The cable is 2 metres long.

What material is the cable jacket made of?

The cable jacket is made of PVC.

What is the diameter of the cable?

The cable has a diameter of 4.8 mm.

Is the cable shielded?

No, the cable is unshielded.

What is the rated voltage for this cable?

The rated voltage is 50 V AC and 60 V DC.

What is the current carrying capacity of the cable?

The cable can carry a current of up to 4A.

What is the operating temperature range for this cable?

The operating temperature range is -5 °C to +80 °C for flexible use and -30 °C to +80 °C for fixed installation.

What is the enclosure rating of the connectors?

The connectors have an enclosure rating of IP65 / IP66K / IP67.
