Specification & Description
| Specification | Description |
|---|---|
| Part Number | WT12-2P410 |
| Alternative Part Number | WT122P410 |
| Manufacturer | Sick |
| Product Type | Photoelectric Proximity Sensor |
| Operating Principle | Direct sensing with background suppression |
| Dimensions (W x H x D) | 15 mm x 49 mm x 41.5 mm |
| Housing Shape | Square |
| Sensing Range | 20 mm to 250 mm |
| Light Type | Infrared light |
| Light Source | LED |
| Adjustment | Potentiometer |
| Supply Voltage | 10 V DC to 30 V DC |
| Ripple | < 5 Vpp |
| Current Consumption | 40 mA (without load) |
| Switching Output | PNP |
| Switching Type | Light/dark switching |
| Response Time | ≤ 330 µs (signal transit time with resistive load) |
| Connection Type | Connector M12, 4-pin |
| Housing Material | Metal, Die-cast zinc |
| Optics Material | Plastic, PMMA |
| IP Rating | IP69K |
| Operating Temperature Range | -40 °C to +60 °C |
| Storage Temperature Range | -40 °C to +75 °C |
| UL File Number | NRKH.E181493 & NRKH7.E181493 |
| Commodity Code | 853650 |
The Sick WT12-2P410 is a state-of-the-art photoelectric proximity sensor designed for precision and reliability in a wide range of industrial applications. This sensor features a robust block design measuring 15 mm x 49 mm x 41.5 mm, making it suitable for tight installation spaces while offering a maximum sensing range of 20 mm to 250 mm. It utilises infrared light as its detection method, ensuring high accuracy in object detection.
Equipped with background suppression technology, the WT12-2P410 excels in environments where the background conditions are variable, as it can distinguish between the target object and the background with great efficiency. The sensor's optics are made from high-quality PMMA plastic, providing durability and consistent performance.
The WT12-2P410 operates on a supply voltage of 10 V DC to 30 V DC and has a low current consumption of 40 mA, making it an energy-efficient choice for continuous operation. It also features a PNP switching output, which can be configured for light or dark operation, and a fast response time of ≤ 330 µs, allowing for quick and responsive automation processes.
For ease of integration, the sensor comes with an M12, 4-pin connector, simplifying the installation process. The housing is made of metal with a zinc die-cast construction, offering a high degree of protection and resilience in harsh industrial environments. The sensor is rated with an IP69K protection class, ensuring it can withstand high-pressure washdowns and extreme temperatures ranging from –40 °C to +60 °C during operation, and storage temperatures from –40 °C to +75 °C.
The Sick WT12-2P410 is a versatile and reliable choice for those seeking a high-quality photoelectric sensor that delivers precision and can withstand the rigours of industrial use.
Commonly Asked Questions
Is my order covered by a warranty?
Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.
Read more...What payment methods do you accept?
We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.
Read more...Is Marvo a credible parts supplier?
Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.
Read more...Have steps been taken to ensure quality control?
Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.
Read more...How do I create an account?
Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.
Read more...Peace of mind with every purchase
Julien
‘Perfect quick delivery, good service.’
Thomas Roland Geaughan
‘Prompt and expert service. Ease of access to find the parts I needed.’
Blažej Knežo
‘Quick response and fast delivery of the product.’
Milan Kosík
‘Large selection of spare parts, fast delivery.’
Irene
‘Fast delivery and prompt action.’
Ms. Mia
‘Quick response, good item, delivery on schedule.’
Dan
‘The ordering was fast and efficient, and everything arrived just as they said it would.’
Andreas Boehm
‘Excellent service. The right gear and the right price,well packed and delivered on time.’
Muswalin
‘Good packing, quickly delivery and responsible.’
Our service to you
Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.
No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.
Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.
Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.
Frequently Asked Questions
What is the operating principle of this photoelectric proximity sensor?
The photoelectric proximity sensor operates on the principle of background suppression, which allows it to detect objects within a certain range while ignoring the background beyond that set distance.
Can this sensor be used in harsh environmental conditions?
Yes, the sensor is designed with a robust housing that can withstand harsh industrial environments, including a wide range of operating temperatures.
What type of light does the sensor use for detection?
The sensor utilises infrared light for object detection, which is emitted from an LED light source within the unit.
How is the detection range of the sensor adjusted?
The detection range can be adjusted using a potentiometer on the sensor, allowing for precise control of the sensing distance.
What are the dimensions of the sensor?
The sensor has compact dimensions, making it suitable for installation in space-constrained areas. The exact dimensions can be found in the product datasheet.
What type of output does the sensor provide?
The sensor provides a PNP output, which is commonly used in industrial control systems for interfacing with various electronic components.
What is the response time of the sensor?
The sensor boasts a quick response time, ensuring timely detection of objects for efficient process control.
What materials are used in the construction of the sensor?
The sensor is constructed with a metal, die-cast zinc housing and a plastic, PMMA optical system, providing durability and reliable performance.
How is the sensor connected to a control system?
The sensor features an M12, 4-pin connector for easy and secure connection to a control system.
Is there an indicator to confirm the sensor is receiving signals?
Yes, the sensor is equipped with a reception indicator that provides visual confirmation of signal reception.
