Specification & Description
| Specification | Description |
|---|---|
| Part Number | WL11-2P2430 |
| Manufacturer | Sick |
| Product Family | W11-2 |
| Type | Miniature Photoelectric Sensor |
| Operating Principle | Reflex Photoelectric Sensor with Dual Lens |
| Dimensions (L x H x W) | 15.6 mm x 48.5 mm x 42 mm |
| Housing Material | Plastic, ABS |
| Optical Material | Plastic, PMMA |
| Supply Voltage | 10 V DC to 30 V DC |
| Ripple | < 5 Vss |
| Current Consumption | 30 mA |
| Switching Output | PNP |
| Switching Function | Antivalent |
| Switching Mode | Light/Dark Switching |
| Signal Voltage PNP HIGH/LOW | Uv - 2.5 V / approx. 0 V |
| Output Current Max | ≤ 100 mA |
| Response Time | ≤ 2.5 ms |
| Switching Frequency | 200 Hz |
| Connection Type | M12, 4-pin connector |
| Circuit Protection | A, C, D |
| Protection Class | II |
| Weight | 120 g |
| Polarisation Filter | Yes |
| Protection Rating | IP66, IP67, IP69K |
| Operating Temperature | -30 °C to +60 °C |
| Storage Temperature | -40 °C to +75 °C |
| Light Source | LED |
| Light Spot Size (at 3 m) | Ø 50 mm |
| Beam Angle | Approx. 2.2° |
| Wavelength | 640 nm |
| Adjustment | None |
| Max Sensing Range | 0.15 m to 10 m |
| Typical Sensing Range | 0.15 m to 8 m |
| UL File Number | NRKH.E181493 & NRKH7.E181493 |
| MTTFD | 3,092 years |
| DCavg | 0% |
| eCl@ss 5.0 | 27270902 |
| eCl@ss 5.1.4 | 27270902 |
| eCl@ss 6.0 | 27270902 |
| eCl@ss 6.2 | 27270902 |
