Specification & Description
| Specification | Description |
|---|---|
| Part Number | ABL8RPS24030 |
| Manufacturer | Schneider |
| Category | General Automation |
| Family | Power Supplies |
| Description | This is a Power Supply Module designed for transformers. It operates within a voltage range of 100 to 500 V ac, providing an output of 24 V dc and 3 A. The module has a power capacity of 72 W and dimensions of 45 x 125 x 143 mm. |
| Input Voltage | 100...120 V AC single phase, terminal(s): N-L1; 200...500 V AC phase to phase, terminal(s): L1-L2 |
| Output Voltage | 24 V DC |
| Output Current | 3 A |
| Power Capacity | 72 W |
| Dimensions | 45 x 125 x 143 mm |
| Efficiency | 87% |
| Inrush Current | 30 A |
| Power Factor | 0.51 at 240 V AC; 0.59 at 120 V AC |
| Output Voltage Adjustment | 24...28.8 V adjustable |
| Power Dissipation | 7.8 W |
| Protection Type | Against overload, overvoltage, short-circuits, undervoltage, and thermal |
| Connections - Terminals | Screw type terminals for input, input ground, output, and output ground |
| Status LED | 1 LED (green and red) for output voltage; 1 LED (green, red and orange) for output current |
| Mounting Support | 35 x 15 mm symmetrical DIN rail; 35 x 7.5 mm symmetrical DIN rail |
| Operating Position | Vertical |
| Dielectric Strength | 3500 V between input and ground; 4000 V between input and output; 500 V between output and ground |
| Environmental Characteristic | EMC conforming to EN 61000-6-1, EN 61000-6-3, EN/IEC 61000-6-2, EN/IEC 61000-6-4, EN/IEC 61204-3; Safety conforming to EN/IEC 60950-1, EN/IEC 61204-3 |
| Operating Altitude | 2000 m |
| IP Degree of Protection | IP20 conforming to EN/IEC 60529 |
| Ambient Air Temperature for Operation | 50…60 °C with derating factor mounting position A < 2000 m; -25…50 °C without derating mounting position A < 2000 m |
| Sustainable Offer Status | Green Premium product |
| REACh Regulation | REACh Declaration |
| EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| EU RoHS Declaration | Yes |
| Mercury Free | Yes |
| China RoHS Regulation | China RoHS Declaration |
| RoHS Exemption Information | Yes |
| Environmental Disclosure | Product Environmental Profile |
| Circularity Profile | End Of Life Information |
| PVC Free | Yes |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. |
The Schneider ABL8RPS24030 is a high-performance power supply module designed for transformers. This robust unit operates within a voltage range of 100 to 500 V AC, providing a steady output of 24 V DC at 3 A. With a power rating of 72 W, it ensures reliable and efficient operation of your industrial equipment. The module features a compact design, measuring 45 x 125 x 143 mm, making it an ideal choice for installations where space is at a premium. It comes with an anti-harmonic filter to manage low-frequency harmonic currents and offers protection against overload, overvoltage, short-circuits, and undervoltage. The ABL8RPS24030 is part of Schneider's renowned Modicon Power Supply family, known for their quality and reliability in various industrial automation applications.
Commonly Asked Questions
Is my order covered by a warranty?
Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.
Read more...What payment methods do you accept?
We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.
Read more...Is Marvo a credible parts supplier?
Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.
Read more...Have steps been taken to ensure quality control?
Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.
Read more...How do I create an account?
Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.
Read more...Peace of mind with every purchase
Anna
‘I can recommend quick, efficient, and professional.’
Martin Ruml
‘Rapid delivery.’
Blažej Knežo
‘Quick response and fast delivery of the product.’
Andreas Boehm
‘Excellent service. The right gear and the right price,well packed and delivered on time.’
Kayden
‘Services is great.’
Ms. Mia
‘Quick response, good item, delivery on schedule.’
Thomas Roland Geaughan
‘Prompt and expert service. Ease of access to find the parts I needed.’
Blažej Knežo
‘Quick response and fast delivery of the product.’
Milan Kosík
‘Large selection of spare parts, fast delivery.’
Our service to you
Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.
No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.
Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.
Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.
Frequently Asked Questions
What is the category of this part?
This part falls under the General Automation category.
What is the family of this part?
This part belongs to the Power Supplies family.
What is the description of this part?
This is a Power Supply Module for Transformer, with an input voltage range of 100 to 500 V ac, output voltage of 24 V dc, current of 3 A, power of 72 W, and dimensions of 45 x 125 x 143 mm.
What is the short description of this part?
This is a Power Supply Module for Transformer, with an input voltage range of 100 to 500 V.
What is the country of origin of this part?
The country of origin for this part is not specified.
What is the commodity code of this part?
The commodity code for this part is 850440.
Can this part be connected in series or parallel?
Yes, the ABL8RPS24030 can be connected in series or parallel. However, it is only recommended for products with identical references. For better availability, the power supplies can also be connected in parallel using the ABL8RED24400 Redundancy module.
What is the input voltage limit of this part?
The input voltage limits for this part are 170 to 550 V AC and 85 to 132 V AC.
What is the efficiency of this part?
The efficiency of this part is 87%.
What is the output voltage adjustment range of this part?
The output voltage adjustment range for this part is 24 to 28.8 V.
What is the power dissipation of this part?
The power dissipation of this part is 7.8 W.
What is the operating position of this part?
The operating position of this part is vertical.
What is the operating altitude of this part?
The operating altitude of this part is 2000 m.
What is the IP degree of protection of this part?
The IP degree of protection for this part is IP20 conforming to EN/IEC 60529.
What is the ambient air temperature for operation of this part?
The ambient air temperature for operation of this part is 50 to 60 °C with derating factor mounting position A < 2000 m and -25 to 50 °C without derating mounting position A < 2000 m.
Is this part a Green Premium product?
Yes, this part is a Green Premium product.
Is this part mercury free?
Yes, this part is mercury free.
Is this part PVC free?
Yes, this part is PVC free.
