Phoenix Contact
PLC-BSC- 24UC/21-21
£38.08 (ex. VAT)
1 ready to ship
Image shown may not reflect the final product
Check similar products or call us on +44 20 4570 3439 for assistance
Express delivery
Lightning fast delivery if ordered within 00:00:00
Hassle-free returns
No hidden fees or duties
Swift dispatch and delivery
Specification & Description
| Specification | Description |
|---|---|
| Part Number | PLC-BSC- 24UC/21-21 |
| Alternative Part Number | PLCBSC24UC2121 |
| Manufacturer | Phoenix Contact |
| Input Voltage | 24 V AC/DC |
| Output Data | Compatible with Miniature relay, REL-MR-24DC/21-21AU, REL-MR-24DC/21-21 |
| Connection Method | Screw connection |
| Stripping Length | 8 mm |
| Screw Thread | M3 |
| Conductor Cross Section Solid | 0.14 mm² ... 2.5 mm² |
| Conductor Cross Section Flexible | 0.14 mm² ... 2.5 mm² (Single ferrule), 2x 0.5 mm² ... 1.5 mm² (TWIN ferrule) |
| Conductor Cross Section AWG | 26 ... 14 |
| Operating Mode | 100% operating factor |
| Mounting Position | Any |
| Assembly Instructions | In rows with zero spacing |
| Color | Gray |
| Flammability Rating | UL 94 V0 (Housing) |
| Ambient Operating Temperature | -40 °C ... 60 °C |
| Ambient Storage Temperature | -40 °C ... 85 °C |
| Width | 14 mm |
| Height | 80 mm |
| Depth | 94 mm |
| Mounting | For mounting on DIN rail NS 35/7,5 |
| Status Display | LED |
| Protective Circuit | Bridge rectifier |
| Approvals | PRS, UL Recognized, cUL Recognized, EAC, DNV GL, cULus Recognized |
| Environmental Compliance | REACh SVHC, China RoHS, Environmentally Friendly Use Period = 50 years |
| Connection in Accordance With | CUL |
| Utilisation Restriction | EMC: class A product |
The Phoenix Contact PLC-BSC- 24UC/21-21 is a versatile and compact relay base designed for seamless integration into industrial control systems. This 14 mm PLC basic terminal block features a screw connection and is engineered to mount on a DIN rail NS 35/7,5. It is equipped to handle 2 PDTs and operates with an input voltage of 24 V AC/DC.
Crafted for reliability and durability, the PLC-BSC- 24UC/21-21 is built to withstand ambient operational temperatures ranging from -40 °C to 60 °C and storage temperatures from -40 °C to 85 °C. The unit's status is easily monitored through its LED status display, and it includes a bridge rectifier as a protective circuit.
The relay base is compatible with miniature relays such as the REL-MR-24DC/21-21AU and REL-MR-24DC/21-21, making it a flexible solution for various applications. Its screw connection method allows for solid and flexible conductor cross sections from 0.14 mm² to 2.5 mm², accommodating a wide range of wiring requirements.
With a flammability rating of UL 94 V0 for the housing and the ability to be mounted in any position, the PLC-BSC- 24UC/21-21 ensures a secure and safe installation. It is also designed for zero spacing in rows, maximising space efficiency on the DIN rail.
This product adheres to stringent industry standards, including cULus Recognized, GOST, GL, and more, ensuring compliance with international regulations. The Phoenix Contact PLC-BSC- 24UC/21-21 is a reliable choice for professionals seeking a high-quality relay base for their control systems.
Commonly Asked Questions
Is my order covered by a warranty?
Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.
Read more...What payment methods do you accept?
We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.
Read more...Is Marvo a credible parts supplier?
Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.
Read more...Have steps been taken to ensure quality control?
Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.
Read more...How do I create an account?
Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.
Read more...Peace of mind with every purchase
Anna
‘I can recommend quick, efficient, and professional.’
Dan
‘The ordering was fast and efficient, and everything arrived just as they said it would.’
Thomas Roland Geaughan
‘Prompt and expert service. Ease of access to find the parts I needed.’
Blažej Knežo
‘Quick response and fast delivery of the product.’
Nathalie Jolicoeur
‘Great service. Thank you.’
Muswalin
‘Good packing, quickly delivery and responsible.’
Julien
‘Perfect quick delivery, good service.’
Thomas Roland Geaughan
‘Prompt and expert service. Ease of access to find the parts I needed.’
Muswalin
‘Good packing, quickly delivery and responsible.’
Our service to you
Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.
No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.
Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.
Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.
Frequently Asked Questions
What type of connection method does this relay base utilise?
The relay base employs a screw connection method for secure and reliable wiring.
Can this relay base be mounted in any position?
Yes, the relay base is designed to be mounted in any position, offering flexibility in installation.
What is the operating temperature range for this relay base?
The operating temperature range for the relay base is from -40 °C to 60 °C, making it suitable for a variety of environmental conditions.
Is there a status indicator on this relay base?
Yes, the relay base features an LED for status indication, providing visual feedback on the operational state.
What is the nominal input voltage for this relay base?
The nominal input voltage for the relay base is 24 V AC/DC.
What is the flammability rating of the housing for this relay base?
The housing of the relay base has a flammability rating of UL 94 V0, indicating that it is flame retardant.
What type of relays are compatible with this relay base?
The relay base is compatible with miniature relays, specifically the REL-MR-24DC/21-21AU and REL-MR-24DC/21-21 models.
What is the conductor cross-section range for connections to this relay base?
The relay base accepts conductor cross-sections ranging from 0.14 mm² to 2.5 mm² for both solid and flexible wires.
What are the dimensions of this relay base?
The dimensions of the relay base are 14 mm in width, 80 mm in height, and 94 mm in depth.
How is this relay base mounted?
This relay base is designed for mounting on a DIN rail, specifically the NS 35/7,5 type, allowing for easy installation in control cabinets and panels.
