Specification & Description
The Phoenix Contact PLC-BPT- 24DC/21 relay base is a compact and reliable interface component designed for seamless integration into industrial automation systems. This relay base is engineered to facilitate easy and secure connections between control logic and field devices. With a nominal input voltage of 24 V DC, it is well-suited for a wide range of DC control circuits.
Crafted with a push-in connection technology, the PLC-BPT- 24DC/21 ensures a quick and tool-free wiring process, significantly reducing installation time. The relay base is compatible with conductor cross sections ranging from 0.14 mm² to 2.5 mm², accommodating both solid and flexible wires, with or without ferrules.
The unit features a robust design with a grey housing that provides a clear visual distinction in complex panels. It is capable of operating in any mounting position, which offers flexibility in design and layout of control cabinets. The relay base also includes an integrated LED status indicator for immediate visual feedback on the operational state.
Designed to fit standard DIN rail mountings, the PLC-BPT- 24DC/21 ensures a secure and stable installation in control panels. Its compact dimensions allow for efficient use of space within electrical enclosures, making it an ideal choice for applications where panel real estate is at a premium.
The Phoenix Contact PLC-BPT- 24DC/21 relay base is a testament to high-quality engineering and is suitable for a variety of industrial applications, including machine control, process automation, and control system design. Its reliability and ease of use make it a valuable component for professionals seeking performance and efficiency in their electrical installations.
Commonly Asked Questions
Is my order covered by a warranty?
Marvo provides a full 12-month warranty on all products, whatever the condition. For your peace of mind, all parts are ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. If you are unhappy with the part(s) you received and would like to request a return, you can do so by completing our quick and easy online form. Once we have received your Returns Request, a member of the team will be in touch to discuss this further with you. You can read more about our warranty policy here.
Read more...What payment methods do you accept?
We accept card payments from all major credit, debit and Mastercard providers including Visa, American Express, Western Union, Paypal and bank transfers. Before you complete an order you will be prompted to input your payment details, at which point you can enter the relevant card information you wish to use for your transaction. If you are experiencing issues with your payment method then you can contact our team via email here. From there, you will be directed to the most relevant resource or person to help you complete your payment, get your order processed and ensure that your parts are on the way to your delivery address.
Read more...Is Marvo a credible parts supplier?
Marvo is a highly credible supplier of industrial automation parts and components with dedicated hubs around the world offering industry-leading products and services. Marvo is committed to providing a quick, easy and reliable place to source your automation and control components. All purchases come as standard with a comprehensive 12-month return to base warranty meaning that, in just a few clicks, you can source critical parts more seamlessly than ever before. Click here to read an article on how Marvo is redefining convenience for automation and manufacturing professionals.
Read more...Have steps been taken to ensure quality control?
Marvo takes pride in product quality and has put several measures in place to assure high levels of quality standards. For your peace of mind, all parts have been ‘Marvo Approved’ which means that they have been tested and checked to ensure that they are in working condition. Redefine convenience and secure priority delivery on all parts along with a comprehensive 12-month warranty. This is the smart new way to buy automation and control components.
Read more...How do I create an account?
Creating an account is incredibly simple and takes a matter of seconds. You can create a Marvo account at any time by clicking here and following the simple steps on screen. By creating a Marvo account you can store your contact details, delivery addresses, billing addresses and more, meaning that you can enjoy game-changing convenience faster than ever before.
Read more...Peace of mind with every purchase
Anna
‘I can recommend quick, efficient, and professional.’
Thomas Roland Geaughan
‘Prompt and expert service. Ease of access to find the parts I needed.’
Martin Ruml
‘Rapid delivery.’
Irene
‘Fast delivery and prompt action.’
Muswalin
‘Good packing, quickly delivery and responsible.’
Advance Lifts
‘Great customer service , we needed some assistance quickly and received it.’
Martin Ruml
‘Rapid delivery.’
Milan Kosík
‘Large selection of spare parts, fast delivery.’
Muswalin
‘Good packing, quickly delivery and responsible.’
Our service to you
Lightning-Fast Express Shipping: Receive your order in record time with our express shipping options, ensuring you minimize downtime and keep your projects on track.
No-Risk Returns, Guaranteed: Return your parts anytime for a full refund. Our hassle-free return policy ensures you’re never stuck with something you don’t need.
Clear Pricing with No Hidden Fees: What you see is what you pay, transparent pricing with no extra costs, ever. Rest assured, all taxes and fees are already included in your final price.
Rock-Solid Reliability at a Fraction of the Cost: Get pre-owned electronic parts that are fully tested for peak performance, saving you money without compromising on quality, backed by a comprehensive warranty.
Frequently Asked Questions
What is the function of a relay base?
A relay base serves as a secure and reliable socket for plug-in relays or solid-state relays. It facilitates easy installation and replacement of the relay while providing the necessary electrical connections and mechanical support.
Can the relay base be mounted on a DIN rail?
Yes, the relay base is designed for mounting on a standard DIN rail, specifically DIN rail NS 35/7,5, which is commonly used in industrial control systems.
What type of connection method does the relay base support?
The relay base supports a push-in connection method, which allows for quick and tool-free wiring of solid and stranded conductors.
Is there any protective circuitry included with the relay base?
Yes, the relay base includes a damping diode and polarity protection diode as part of its protective circuitry.
What is the nominal input voltage for this relay base?
The nominal input voltage for the relay base is 24 V DC, which is a standard voltage level for many control systems.
Are there any accessories available for the relay base?
Yes, there are various accessories available such as separating plates, power terminal blocks, and different types of marker strips for terminal labelling.
What is the operating temperature range for the relay base?
The operating temperature range for the relay base is from -40 °C to 60 °C, making it suitable for a wide range of industrial environments.
How can I identify the relay base in a control panel?
The relay base can be identified by its colour, which is typically grey, and by the presence of a status LED for visual indication.
What are the dimensions of the relay base?
The dimensions of the relay base are width 6.2 mm or 14 mm, height 80 mm, and depth 94 mm, depending on the specific model.
Does the relay base have any certifications or approvals?
Yes, the relay base has several certifications and approvals, including UL Recognized, cUL Recognized, and EAC, ensuring compliance with various international standards.
